Hacienda West

Project Description

Located on a total area of 602,702 m2 (143,5 acres) in Marsa Matrouh, the project comprises the following components:

  1. Ground and First Floors Villas
  • Type 5 (BUA: 340m2)
  • Type 7 (BUA: 264m2)
  • Type 8 (BUA: 197m2)
  1. Chalets
  • Junior Chalet (BUA: 470 m2)
  • Senior Chalet (BUA: 662m2)
  • 3 in 1 Chalet (BUA: 506 m2)
  1. Ground and Two Floors Apartment Buildings

Two types of apartment buildings, including units with approximate areas ranging from 100 m2 to 155 m2:

  • Type 1: Hazel buildings, each including 15 units with a total BUA of 2,160 m2
  • Type 2: Pine buildings, each including 10 units with a total BUA of 1,070m2
  1. Cabanas
  • Residential cabanas with a BUA of 9,760 m2
  • Hotel cabanas with a BUA of 13,282 m2
  1. Gates and Fences: Two gates with a BUA of 18 m2

Infrastructure works include:

  • Road Network: with a total length of 11,135 m and width ranging from 11 m to 25 m
  • Water Supply Network: with a total length of 11.5 km and diameters ranging from 75 mm to 315 mm, including water tanks with a capacity of 4,700 m3 and RO Desalination Plant with a capacity of 3,400 m3/day
  • Sewage Network: with a length of 16 km and diameters ranging from 160 mm to 500 mm, including a Compact Unit WWTP with a capacity of 1,600 m3/day and Sewage Pump Station with a rate of 33 l/sec
  • Firefighting Network
  • Irrigation Network: with a length of 15 km and diameters ranging from 75 mm to 315 mm, including irrigation tanks with a capacity of 2,800 m3
  • Electricity, Street Lighting, and Ancillary Buildings
  • Storm Drainage Network: with a length of 1.2 km and diameters ranging from 160 mm to 600 mm, including a storm tank with a capacity of 1,400 m3
  • Tie-ins for Landscape, Fence Lighting Network, and Gates
  • Communications and Security Systems Network
  • Subsoil Drainage

Activities

  • Architectural
  • Civil Works
  • Communications and security systems
  • Electrical
  • HVAC
  • Mechanical
  • Roads
  • Structural
  • Urban design

Scope

  • Construction documents
  • Detailed design
  • Master plan
  • Schematic design
  • Tender documents

Client

Palm Hills for Touristic & Real Estate Development

LOCATION

egypt

,
